VSG-24 Series Indoor High Voltage Vacuum Circuit Breaker
VSG-24 series indoor high voltage vacuum circuit breaker is a 3-phase AC 50Hz 24kV indoor switch equipment
♦ Operating mechanism: spring operating mechanism;
♦ Pole type: assembled pole: embedded pole;
♦ phase-to-phase distance: 275mm;
XUCKY Electric is a leading China manufacturer and exporter specializing in VSG-24 Series Indoor High Voltage Vacuum Circuit Breaker. We have a wide range of products to meet the different needs of our customers worldwide. Our commitment to superior quality, innovative technology and excellent customer service makes us stand out in our industry.
VSG-24 indoor HV vacuum circuit breaker is a 3- phase AC 50Hz 24kV indoor switch equipment
♦ Operating mechanism: spring operating mechanism;
♦ Pole type: assembled pole: embedded pole;
♦ phase-to-phase distance: 275mm;
Environmental Conditions
♦ Ambient temperature: -15°C 〜+40°C;
♦ Altitude: <1000m;
♦ Relative humidity: daily average <95%, monthly average <90%;
♦ Earthquake intensity: <8 level;
♦ Places without fire, explosion hazard, serious filthy, chemical corrosion, as well as intense vibration.
Main Technical Parameters
No
Item
Unit
Value
1
Rated voltage
kV
24
2
1 min power frequency withstand voltage
65
3
Rated lightning impulse withstand voltage
125
4
Rated frequency
Hz
50/60
5
Rated current
/
630, 1250, 1600, 2000, 2500,3150
6
Rated short circuit breaking current
kA
25, 31.5
7
Rated short circuit making current (peak)
63, 80
8
Rated short time withstand current
25, 31.5
9
Rated peak value withstand current
63, 80
10
Rated short circuit duration
S
4
11
Rated operating sequence
O-0.3s-CO-180s-CO
12
Secondary circuit power frequency withstand voltage (1min)
V
2000
13
Rated single/back-to-back capacitor bank breaking current
kA
630
14
Breaking time
ms
20 〜50
1;
Opening time
35-70
16
Mechanical life
times
10000
17
Electrical life
E2 class
18
Power of energy storage motor
W
90
19
Control circuit power supply voltage
V
AC/DC110/220
General Structure Drawing and Installation Size (unit: mm)
♦ Draw out type
Rated current (A)
630
1250
1600
Rated short circuit breaking current (kA)
25, 31.5
25, 31.5
31.5
Fixed contact size (mm)
035
049
055
Phase-to-phase distance (mm)
275
